SKU: HIK-DS-KD-KP
MPN: DS-KD-KP
UPC: 842571125184
Keypad module for modular video intercom door station, twelve keys for calling recipients and unlocking door with codes, requires main video module and mounting bracket, IP65
Send to a friend!
| Manufacturer | Hikvision |
| Manufacturer Part Number | DS-KD-KP |
| Product Model | DS-KD-KP |
| Product Name | KD8 Series Pro Modular Door Station |
| Product Type | Intercom System Keypad Module |
| Device Supported | Intercom System |
| Features | Backlit Keypad, Flush Mount, Surface Mount |
| Depth | 1.3″ |
| Height | 3.9″ |
| Weight (Approximate),Width | 9.35 oz,3.9″ |
| Additional Information,Certifications & Standards,Environmentally Friendly | System Parameters: Processor: Embedded MCU Processor General: Power consumption: ? 2 W Output power: 12 VDC (powered for the other module) IP protection level: IP65, IK7 Working temperature: -40° C to +55° C(-40° F to 131° F) Working humidity: 10% to 95% Device Interfaces: Module connecting: 2 (1 input, 1 output) Debug: 1,IP65 IK7 CE-EMC: a. EN 55032:2015 b. EN 61000-3-2:2014 c. EN 61000-3-3:2013 d. EN 50130-4:2011 +A1:2014 CE-LVD: EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 CB: IEC 60950-1:2005 (Second Edition) + Am 1:2009 + Am 2:2013 FCC-SDOC: 47 CFR Part 15, Subpart B CTICK(EMC): AS/NZS CISPR 32:2015 UL: UL 60950-1 CAN/CSA C22.2 No. 60950-1-07, Information Technology Equipment – Safety – Part 1: General Requirements IC: ICE-003: Issue 6,Yes |
| Application/Usage,Environmental Certification | Door,REACH, RoHS, WEEE |
| Manufacturer | Hikvision |
| Manufacturer Part Number | DS-KD-KP |
| Product Model | DS-KD-KP |
| Product Name | KD8 Series Pro Modular Door Station |
| Product Type | Intercom System Keypad Module |
| Device Supported | Intercom System |
| Features | Backlit Keypad, Flush Mount, Surface Mount |
| Depth | 1.3″ |
| Height | 3.9″ |
| Weight (Approximate),Width | 9.35 oz,3.9″ |
| Additional Information,Certifications & Standards,Environmentally Friendly | System Parameters: Processor: Embedded MCU Processor General: Power consumption: ? 2 W Output power: 12 VDC (powered for the other module) IP protection level: IP65, IK7 Working temperature: -40° C to +55° C(-40° F to 131° F) Working humidity: 10% to 95% Device Interfaces: Module connecting: 2 (1 input, 1 output) Debug: 1,IP65 IK7 CE-EMC: a. EN 55032:2015 b. EN 61000-3-2:2014 c. EN 61000-3-3:2013 d. EN 50130-4:2011 +A1:2014 CE-LVD: EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 CB: IEC 60950-1:2005 (Second Edition) + Am 1:2009 + Am 2:2013 FCC-SDOC: 47 CFR Part 15, Subpart B CTICK(EMC): AS/NZS CISPR 32:2015 UL: UL 60950-1 CAN/CSA C22.2 No. 60950-1-07, Information Technology Equipment – Safety – Part 1: General Requirements IC: ICE-003: Issue 6,Yes |
| Application/Usage,Environmental Certification | Door,REACH, RoHS, WEEE |
