Image Sensor
1/2.8″-Type CMOS
Focal Length
2.8mm
Field of View
Horizontal: 107°
Vertical: 57°
Diagonal: 128°
Pan/Tilt
No
Built-In Microphone
Yes
Power I/O
1x DC
1x RJ45
Imaging
Lens Mount
M12
Number of Lenses
1
Image Sensor
1/2.8″-Type CMOS
Sensor Resolution
Effective: 8 Megapixel
IR Cut Filter
Yes Mechanical
Day/Night
Yes
Exposure Control
Minimum Illumination
0.005 Lux (Color)
0 Lux (Black and White)
Lens
Focal Length
2.8mm
Field of View
Horizontal: 107°
Vertical: 57°
Diagonal: 128°
Maximum Aperture
f/1.6
Video
Automatic Gain Control
Yes
Max IP Streaming
via RJ45
3840 x 2160 up to 20 fps
3200 x 1800 up to 30.00 fps
Multi-View Streaming
Yes, 3 Streams
Control
Camera Angle Adjustment
Horizontal: 0 to 360°
Vertical: 0 to 75°
Pan/Tilt
No
Networking
Security
Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, Password Protection
Supported Protocols
Bonjour, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, NTP, PPPoE, QoS Layer 3 DiffServ, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), SSL/TLS, TCP, UDP, UPnP, ONVIF Profile S, ONVIF Profile G, ISAPI, SDK
Interface
Media/Memory Card Slot
Single Slot: microSD/microSDHC/microSDXC [256 GB Maximum]
Other I/O
1x RJ45
1- or 2-Way Audio
One-Way
Audio Formats
AAC, G.711, G.722.1, G.726, MP2L2, MP3, PCM
Built-In Microphone
Yes
External Storage Options
NAS
System Integration
Analytics
Motion Detection, People Detection, Vehicle Detection, Camera Sabotage/Tampering, Face Detection, Virtual-Line Crossing Detection, Intrusion Detection
Built-In Installation Aids
Pixel Counter
Sensors & Alarms
Event Trigger
Yes
Event Action
Recording, Notification, Alarm
Power
Power I/O
1x DC
1x RJ45
Power Consumption
Power Supply: 6 W
PoE: 7.5 W
General
Material of Construction
Aluminum
Environmental Resistance
Dust/Water-Resistant (IP67)
Operating Conditions
-22 to 140°F / -30 to 60°C up to 95% Humidity
Startup Temperature
-22 to 140°F / -30 to 60°C
Storage Conditions
-22 to 140°F / -30 to 60°C
Illumination
850 nm IR LEDs up to 98.4′ / 30 m
Supported Languages
Brazilian Portuguese
Bulgarian
Croatian
Czech
Danish
Dutch
English
Estonian
Finnish
French
German
Greek
Hungarian
Italian
Japanese
Korean
Latvian
Lithuanian
Norwegian
Polish
Portuguese
Romanian
Russian
Serbian
Slovak
Slovenian
Spanish
Swedish
Thai
Traditional Chinese
Turkish
Ukrainian
Vietnamese
OS Compatibility
Android/iOS
Mobile App Compatible
Yes: Android & iOS
Dimensions (W x H x D)
5 x 3.8″ / 127.3 x 95.9 mm
Weight
1.3 lb / 600 g (Body Only)
Packaging Info
Package Weight
2.265 lb
Box Dimensions (LxWxH)
6.6 x 6.1 x 5.6″
