Hikvision DS-2CD2383G2-I 2.8MM(BLK)

SKU: HIK-DS-2CD2383G2-I 2.8MM(BLK)

MPN: DS-2CD2383G2-I 2.8MM(BLK)

UPC: 842571138573

Description

Black Outdoor Turret, 8MP-30fps, H265+, 2.8mm, Day/Night, 120dB WDR, EXIR 2.0 (40m), Human and vehicle targets classification based on deep learning, IP67,PoE/12VDC

Add to Wishlist

Send to a friend!

Image Sensor
1/2.8″-Type CMOS
Focal Length
2.8mm
Field of View
Horizontal: 107°
Vertical: 57°
Diagonal: 128°
Pan/Tilt
No
Built-In Microphone
Yes
Power I/O
1x DC
1x RJ45
Imaging
Lens Mount
M12
Number of Lenses
1
Image Sensor
1/2.8″-Type CMOS
Sensor Resolution
Effective: 8 Megapixel
IR Cut Filter
Yes Mechanical
Day/Night
Yes
Exposure Control
Minimum Illumination
0.005 Lux (Color)
0 Lux (Black and White)
Lens
Focal Length
2.8mm
Field of View
Horizontal: 107°
Vertical: 57°
Diagonal: 128°
Maximum Aperture
f/1.6
Video
Automatic Gain Control
Yes
Max IP Streaming
via RJ45
3840 x 2160 up to 20 fps
3200 x 1800 up to 30.00 fps
Multi-View Streaming
Yes, 3 Streams
Control
Camera Angle Adjustment
Horizontal: 0 to 360°
Vertical: 0 to 75°
Pan/Tilt
No
Networking
Security
Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, Password Protection
Supported Protocols
Bonjour, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, NTP, PPPoE, QoS Layer 3 DiffServ, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), SSL/TLS, TCP, UDP, UPnP, ONVIF Profile S, ONVIF Profile G, ISAPI, SDK
Interface
Media/Memory Card Slot
Single Slot: microSD/microSDHC/microSDXC [256 GB Maximum]
Other I/O
1x RJ45
1- or 2-Way Audio
One-Way
Audio Formats
AAC, G.711, G.722.1, G.726, MP2L2, MP3, PCM
Built-In Microphone
Yes
External Storage Options
NAS
System Integration
Analytics
Motion Detection, People Detection, Vehicle Detection, Camera Sabotage/Tampering, Face Detection, Virtual-Line Crossing Detection, Intrusion Detection
Built-In Installation Aids
Pixel Counter
Sensors & Alarms
Event Trigger
Yes
Event Action
Recording, Notification, Alarm
Power
Power I/O
1x DC
1x RJ45
Power Consumption
Power Supply: 6 W
PoE: 7.5 W
General
Material of Construction
Aluminum
Environmental Resistance
Dust/Water-Resistant (IP67)
Operating Conditions
-22 to 140°F / -30 to 60°C up to 95% Humidity
Startup Temperature
-22 to 140°F / -30 to 60°C
Storage Conditions
-22 to 140°F / -30 to 60°C
Illumination
850 nm IR LEDs up to 98.4′ / 30 m
Supported Languages
Brazilian Portuguese
Bulgarian
Croatian
Czech
Danish
Dutch
English
Estonian
Finnish
French
German
Greek
Hungarian
Italian
Japanese
Korean
Latvian
Lithuanian
Norwegian
Polish
Portuguese
Romanian
Russian
Serbian
Slovak
Slovenian
Spanish
Swedish
Thai
Traditional Chinese
Turkish
Ukrainian
Vietnamese
OS Compatibility
Android/iOS
Mobile App Compatible
Yes: Android & iOS
Dimensions (W x H x D)
5 x 3.8″ / 127.3 x 95.9 mm
Weight
1.3 lb / 600 g (Body Only)
Packaging Info
Package Weight
2.265 lb
Box Dimensions (LxWxH)
6.6 x 6.1 x 5.6″

AcuSense technology minimizes false alarms caused by moving targets that aren’t humans or vehicles to improve efficiency and effectiveness
IR cut filter for day and night functionality
H.265+, H.265, H.264+, H.264, and MJPEG video compressions
CBR and VBR
Scalable Video Coding (SVC) for H.264 and H.265 encoding
Slow shutter support
Three-axis angle adjustment (0 to 360° horizontal pivot, 0 to 75° vertical pivot, and 0 to 360° rotation)
120 dB wide dynamic range
3D-DNR, backlight compensation, and highlight compensation
Image settings include; rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, and white balance
Image parameters switch
Region of interest supports one fixed region for main stream and sub-stream separately
Analytics include; motion detection, video tampering alarm, exception, face detection, and perimeter protection
General functions include; anti-flicker, heartbeat, password reset via email, and pixel counter
Hardware and software reset
Up to 32 users with three host levels (admin, operator, and user)
Up to six channels in simultaneous live view
100M self-adaptive RJ45 Ethernet port
Built-in microphone
Environment noise filtering
Compatible with Internet Explorer 10 and 11 (plug-in required), Chrome 57 or higher, Firefox 52 or higher, iOS, Android, iVMS-4200, Hik-Connect, and Hik-Central
Network-attached storage support

3840 x 2160 Resolution at 20 fps
IR LEDs for Night Vision up to 98′
2.8mm Fixed Lens
107° Horizontal Field of View
Built-In Microphone
microSD Slot Supports up to 256GB
RJ45 Ethernet with PoE Technology
Complies with ONVIF Profiles G & S
IP67 Rated for Outdoor Use

Color:
Black
Brand:
Hikvision

Monitor an indoor or outdoor area with the white AcuSense DS-2CD2383G2-IU 8MP Network Turret Camera from Hikvision. This unit uses a 1/2.8″ progressive scan CMOS sensor to capture 3840 x 2160 resolution video at 20 fps. IR LEDs provide up to 98′ of night vision. The camera’s 2.8mm fixed lens delivers a 107° horizontal field of view. A built-in microphone enables the camera to pick up audio. A memory card slot accepts microSD/SDHC/SDXC cards up to 256GB (available separately). Integrated PoE technology simplifies connectivity by enabling the transfer of power and data through a single cable.

This turret camera complies with ONVIF profiles G and S, making it compatible with a wide range of surveillance devices. The camera’s aluminum enclosure is IP67 rated for outdoor use.
