Blustream CMX42AB

SKU: BLU-CMX42AB

MPN: CMX42AB

Description

BLUSTREAM Remote Control for the CMX42AB

Add to Wishlist

Send to a friend!

Processing

Switching Type	IR Remote, Pushbutton, Software
Processing Resolution	UHD 4K at 60
Color Processing	4:4:44:2:0

Input

Video Inputs	4x HDMI (2.0) Female
Input Video Format	HDMI (4:4:4/4:2:0)UHD 4K up to 60 fps
Embedded Audio Input	HDMI

Output

Video Outputs	2x HDMI (2.0) Female
Output Video Format	HDMI (4:4:4/4:2:0)UHD 4K up to 60 fps
Audio Outputs	2x RCA 8-Channel S/PDIF Female2x 1/8″ / 3.5 mm TRS Stereo Analog Female
Output Audio Format	S/PDIFAnalog
Embedded Audio Output	HDMI: 8-Channel (per Output)

Connectivity

Other I/O	1x DE-9/DB-9 RS-232 Input/Output3x 1/8″ / 3.5 mm IR Input4x 1/8″ / 3.5 mm IR Output
HDCP Support	Yes, Version 2.2
DTS Compatibility	DTS, DTS 96/24, DTS Digital Surround, DTS Express, DTS Neo:6, DTS Neural:X, DTS Virtual:X, DTS-ES, DTS-HD Express, DTS-HD High Resolution, DTS-HD Master Audio, DTS:X, DTS:X Pro
Dolby Compatibility	Dolby Atmos, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Dual Mono, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Wi-Fi	No
Bluetooth	No

Power

Power I/O

1x Barrel (12 VDC at 2 A) Input

General

Operating Conditions	32 to 104°F / 0 to 40°C
Storage Conditions	-4 to 140°F / -20 to 60°C
Certifications	FCC, CE, RoHS, CANICES-3
Rack Form Factor	1 RU
Dimensions	10 x 4.1 x 1.6″ / 255 x 104 x 40mm

Key Features

Matrix Switcher with Audio Breakout
4 x HDMI Inputs, 2 x HDMI Outputs
2 x Analog & Coaxial Digital Outputs
Down-Conversion on All HDMI Outputs

Route up to four HDMI 2.0 UHD 4K inputs to up to two displays or to other HDMI-compatible destinations with the Contractor 4×2 HDMI 2.0 4K Matrix with Audio Breakout and RS-232 Control from Blustream. This versatile matrix switcher also de-embeds audio with breakout to two digital coaxial ports and/or two analog 3.5mm ports. The Contractor supports all known HDMI audio formats, input and output resolutions up to UHD 4K60 with 4:4:4 chroma sampling, and down-conversion on all four HDMI outputs. The unit can be controlled via front-panel buttons, IR with the included remote, and RS-232 via an optional controller. The HDCP 2.2 compliant device boasts advanced EDID management and HDR support. The package includes a 12 VDC power supply.

Type:
HDMI Matrix
Outputs:
2
Inputs:
4
Resolution:
4K Ultra HD
Brand:
Blustream
