3xLogic TP5P01

1 65B8264 Flange
1 65B8265 Retainer
1 80A439 Isolation Ring
1 RK412WS Snap-fit Foam Windscreen (1 furnished, 4 in replacement kit)
1 A400SM Shock Mount
1 80A67 Hex Wrench #4

Engineered to capture and inspire.
Gooseneck length: 12 inch (30.5 cm)
Interchangeable cartridges provide the right polar pattern for every application
Locking flange mount for permanently securing microphone to surfaces
Snap-fit foam windscreen
Shock mount provides over 20 dB isolation from surface vibration noise
Wide dynamic range and frequency response for accurate sound reproduction across the audio spectrum
Balanced, transformerless output for increased immunity to noise over long cable runs
New RF filtering
Interchangeable Cartridge
Designed for easy replacement and available in cardioid, supercardioid and omnidirectional polar patterns, the interchangeable cartridges offer wide frequency response and accurate sound reproduction for a broad variety of applications, such as houses of worship, courtrooms and conference centres. Plus, the condenser cartridges fit every model in the Microflex product line for enhanced convenience and consistent sound.

Available Options
Microflex Gooseneck microphones are available in four models with a variety of heights and mounting styles to choose from. One model includes a silent mute switch with LED indicator, a Shure Microflex exclusive. And every Microflex Gooseneck features high sensitivity and balanced, transformerless output for maximum immunity to electromagnetic hum and RF interference, even over long cable runs. Each Microflex Gooseneck microphone comes with a complete installation kit, including locking metal and foam ball windscreens, snap-in and shock-mount microphone stand adapters.

Connect the S1 Unit to Power and the Alarm Panel.
The power cable and relay contacts are connected to the 8 Pin Quick Connector
on the board in the back of the unit pictured below.

Gunshot Detection from 3xLOGIC is a sensor that detects the shockwave / concussive signature of any gun caliber. It detects up to 75 feet in all unobstructed directions or 150 feet in diameter. The smaller directional sensor that detects the strongest signal determines the source of the gunshot. The sensor is a stand-alone product that can send gunshot detection information using its on-board processors to a variety of host systems including alarm panels, central stations, video management systems, access control systems and other critical notification systems. No other equipment is necessary for the sensor to identify a gunshot. It is a self-contained device that can complement any security system. 3xLOGIC Gunshot Detection can be used as a single device or is scalable in design and deployments can include an unlimited number of sensors.
